| Specifications for CHB-V5600 Veterinary Ultrasound Scanner | |
| Body marks |
1. General 2. Bovine 3.Canine 4.Equine 5.Feline 6.Cardio 7. Swine, 27 kinds of body marks indicating probe position; |
| Display mode | B,2B,4B, B/M, M |
| Adjustable depth | 10 grades, max depth of 236mm |
| Gain | 0~127dB |
| Contrast | 27~90dB |
| Gray scale | 256 |
| Image storage | 4G hard disk to permanently store about 5000 frames images |
| Cine loop | 256 frames |
| Cardio measurement | Depth, slope, heart rate, cycle |
| Normal measurement | Distance, circumference, area (trochoid or ellipse), volume, etc |
| OB measurement including |
Cattle, dogs, horses, cats, goats, camels and sheep and pre-gestational age birth |
| Other measurements | pig's meat factor measurement |
| Dual TV output | PAL/NTSC, can connect video printers when necessary |
| Power supply | 100-240V~ 1.2-0.6A frequency:50-60Hz |
| Power supply adaptor output | DC12.8V 3.0A |
| Main unit weight | 4.5kg(without accessories) |
| Main unit dimension | 256×150×326mm(L×W×H) |
